BA40XX-XXXX-X
โพสต์เมื่อ : 18 มิ.ย 2562 เวลา 14:36 น.
| BA | 40XX- | X | X | X | X | -X |
|---|---|---|---|---|---|---|
| Center body | Housing material | Seat material | Ball material | Diaphragm material | O-ring material | Port |
| Aluminum alloy | PP - Polypropylene SS - Stainless steel CS - Carbon steel AL - Aluminum | P - Polypropylene S - Stainless steel C - Carbon steel 0 - Aluminum 9 - Santoprene® | 9 - Santoprene® H - Hytrel® T - PTFE 8 - Santoprene® w/steel core P - UPE | 9 - Santoprene® H - Hytrel® T - PTFE/Santoprene® | 0 - Non 1 - NBR 3 - PTFE(FULL) 4 - PTFE(COVER） | A - BSP (thread) C - Flange |
Pump Data
| Working air pressure | 0.10-0.83 Mpa |
| Maximum outlet pressure | 0.83 Mpa |
| Maximum flow rate | 378.5 lpm |
| Maximum particle size | 6 mm |
| Maximum dry suction | 6.7 m |
| Noise level @70psi | 75 dB |
| Weight | |
| Plastic | 19 kg |
| Stainless steel | 30 kg |
| Carbon steel | 30 kg |
| Aluminum | 18 kg |
